Fuel Cell Genset Integrations
Our hydrogen fuel cell technology offers a solution for the next generation telecom networks. Hydrogen fuel cells provide zero-emissions power, reduce the carbon footprint and ensure strong, uninterrupted service. It’s a win for connectivity and for the planet.
PowerCell Group products generate electric power with minimal environmental impact using zero-emission hydrogen fuel cell technology. Power Generation System 5 is a hydrogen fuel cell system developed to create electricity in an environmentally friendly, silent, and reliable way. The system is based on our V Stack and can be used as a generator for buildings and households and as a backup generator for telecom. The system is designed for simple integration. It is built onto a standard 19-inch rack with multiple protective safeguards to minimize the risks and consequences of any foreseeable hazards to the system.
| Max net power | 5 kW |
| Gross output (at rated power) | 45 V / 140 A |
| Voltage output | 25-59 VDC |
| Current output | Up to 80 A per two battery output connections |
| System heat output | 0–7.5 kW |
| Coolant outlet temperature | 65°C |
| Fuel quality | Hydrogen ISO 14687:2019 |
| Fuel inlet pressure | 3–6 bar(g) |
| Communication and control | CAN 500 kpbs and interface display control |
PowerCell Group products generate electric power with minimal environmental impact using zero-emission hydrogen fuel cell technology. P System 100 is a powerful fuel cell system with 100 kW of maximum power and integration into a wide range of hydrogen inlet pressures. With the possibility of operating at a very low inlet pressure, the system is compatible with components that enable compatibility with future renewable fuels. It is suitable for integration in both primary and backup power generators. It can also be used in a combined heat and power unit. The system has a durable construction meant to ensure lasting and reliable use over time. The product is available in three different power output alternatives: 60, 80 and 100 kW.
| Net power output | 60 – 100 kW |
| Gross output (rated power) | 300 V / 380 A |
| Voltage output | 250 – 500 V |
| Current output | 50 – 450 A |
| System heat output (max) | < 140 kW + 11 kW |
| Coolant outlet temperature | 80°C |
| Fuel quality | Pure hydrogen |
| Fuel inlet pressure | 0.5 - 3 Bar (g) / 3 - 8 Bar (g) / 8 - 12 Bar (g) |
| Communication and control | CAN bus 500 kpbs |
PowerCell Group products generate electric power with minimal environmental impact using zero-emission hydrogen fuel cell technology. Power Generation System 200 is a powerful yet compact fuel cell system with a net electric output of 200 kW operable at a wide range of hydrogen inlet pressures. With the possibility of operating at a very low inlet pressure, the system is compatible with equipment, which in turn enables the use of different renewable fuels. Power Generation System 200 offers high system efficiency and delivers silent and emission-free electricity.
| Net power (DC Supply) | 200 kW |
| Dimensions (width x depth x height) | 730 x 900 x 2200 mm |
| Weight | 1070 kg |
| Gross output (rated power) | 580 V / 400 A |
| Voltage output | 550 - 1000 VDC |
| Current output stack | 50 - 450 A |
| Heat output | < 330 kW |
| Ambient temperature | Indoors with Pollution Degree 3 or higher |
| Fuel inlet pressure | 0.5 - 3 Bar (g) / 3 - 8 Bar (g) / 8 - 12 Bar (g) |
| Temperature | 5 to 45 °C |
Get in touch with one of our experts in the field of hydrogen electric fuel cells. Our team can support you from pre-study, to integration and commissioning.
